Physical Specifications RG-AP810-L Dimensions (W × D × H) 220mm×220mm×49mm Weight Device：0.6kg Mounting Kit：0.2kg Installation Ceiling / Wall Anti-theft Lock Support Radio Specifications RG-AP810-L Radio Dual-radio dual-band: Radio1：2.4GHz 11ax，2×2 MIMO Radio2：5GHz 11ax，2×2 MIMO Operating Band Radio1: 802.11b/g/n/ax，2.4GHz～2.483GHz，HE40 Radio2： 802.11a/n/ac/ax，5.150GHz～5.350GHz，HE80 802.11a/n/ac，5.470GHz～5.725GHz，5.725GHz～5.850GHz，HE80 Note: vary depending on different countries Max Throughput Radio1：2.4GHz，0.574Gbps Radio2：5GHz，1.201Gbps Maximum throughput per AP: 2.4GHz+5GHz，1.775Gbps Antenna Type Integrated Omnidirectional Antenna Gain 2.4GHz： 3dBi 5GHz： 3dBi Transmit Power 20dBm Note: vary depending on different countries Adjustable Power 1dBm Modulation OFDM：BPSK@6/9Mbps，QPSK@12/18Mbps，16-QAM@24Mbps，64-QAM@48/54Mbps DSSS：DBPSK@1Mbps，DQPSK@2Mbps，and [email protected]/11Mbps MIMO-OFDM：BPSK，QPSK，16QAM 、64QAM 、256QAM and1024QAM OFDMA Interfaces RG-AP810-L Interfaces 1 10/100/1000M BASE-T Ethernet Port, PoE In (Support IEEE 802.3af) Full Spectrum Operation in IEEE 802.3af Mode Bluetooth BT 5.1 Management Port 1 RJ45 Console Port LED Indicator 1 LED Indicator Reset Button Support Power RG-AP810-L Power Supply Local Power Supply (DC 48V/0.6A) Note: DC power adapters should be purchased separately from third-party vendors if needed. PoE（IEEE 802.3af Standard）- Full Spectrum Operation Power Consumption 12.95W Environment RG-AP810-L Temperature Operating Temperature: -10°C～50°C Storage Temperature: -40°C～70°C Humidity Operating Humidity: 5%~95% (non-condensing) Storage Temperature: 5%~95% (non-condensing) IP Rating IP41 Safety Standard GB 4943.1-2011，IEC 62368-1 EMC Standard EN 300386,GB/T 19286-2015,GB/T 17618-2015 Software Specifications RG-AP810-L WLAN Maximum Clients: 512 Recommended Client: 120 SSID Hiding: Support 5G Priority (Band Steering): Support
