Product code: N/A

IP Kamera Hikvision 2MP Darkfighter DS-2CD2125FHWD-IS

Rp 2,350,000

IP Kamera 2MP Hikvision Up to 2 megapixel high resolution Max. 1920 × 1080 @60fps 2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional Powered by Darkfighter H.265, H.265 , H.264 , H.264 120dB Wide Dynamic Range 3D Digital Noise Reduction DC12V & PoE (802.3af) IR range: up to 30 m Support on-board storage, up to 128 GB IP67, IK10

More about this item

IP Kamera Hikvision 2MP Darkfighter DS-2CD2125FHWD-IS

Camera
Image Sensor:		1/2.8″ Progressive Scan CMOS
Signal System:		PAL/NTSC
Min. Illumination:		Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter time:		1/3 s to 1/100,000 s
Slow shutter:		Support
Lens:		2.8 mm, horizontal field of view: 108° 4 mm, horizontal field of view: 86.4° 6 mm, horizontal field of view: 52° 8 mm, horizontal field of view: 41° 12 mm, horizontal field of view: 25°
Lens Mount:		M12
Adjustment Range:		Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Day& Night:		IR cut filter with auto switch
Wide Dynamic Range:		120 dB
Digital noise reduction:		3D DNR
Focus:		Fixed

Compression Standard
Video Compression:		H.265 /H.265/H.264 /H.264/MJPEG
Video bit rate:		32Kbps~16Mbps
Audio Compression:		-S: G.711/G.722.1/G.726/MP2L2/PCM
Audio bit rate:		64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Triple Streams:		Yes

Max. Image Resolution:		1920 x 1080
Frame Rate:		50Hz: 50fps (1920 × 1080, 1280 × 960, 1280×720) 60Hz: 60fps (1920 × 1080, 1280 × 960, 1280×720)
Sub Stream:		50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:		50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240)
Image Enhancement:		BLC/3D DNR/HLC
Image Settings:		Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
ROI:		Support 1 fixed region for main stream and sub stream separately
Day/Night Switch:		Day/Night/Auto/Schedule/Triggered by Alarm In (-S)

Network
Network Storage:		microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger:		Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols:		TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
General Function:		One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
System Compatibility:		ONVIF (Profile S, Profile G), ISAPI

Interface
Audio:		with -S model：1 audio input (line in), 1 audio output interface, terminal block
Communication Interface:		1 RJ45 10M / 100M Ethernet interface
Alarm:		with -S model : 1 alarm input, 1 alarm output (max. 12 VDC, 30 mA), terminal block
On-board storage:		Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button:		Yes

Audio
Environment Noise Filtering:		Support(-S)
Audio I/O:		support
Audio Sampling Rate:		8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz

Smart Feature-set
Behavior Analysis:		Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
Line Crossing Detection:		Cross a pre-defined virtual line
Intrusion Detection:		Enter and loiter in a pre-defined virtual region
Unattended Baggage:		Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal:		Objects removed from the pre-defined region, such as the exhibits on display.
Exception Detections:		Scene change detection
Recognition:		Face Detection

General
Operating Conditions:		-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:		12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption:		12 VDC ± 25%, 5W PoE(802.3af, class 3), 6.5W
Impact Protection:		IK10
Weather Proof:		IP67
IR Range:		Up to 30m
Dimensions:		Camera: Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″) Package: 134 × 134 × 108 mm (5.27″ × 5.27″ × 4.25″)
Weight:		Camera: 500 g (1.1 lb.)
