- IP Camera 2MP Hikvision DS-2CD2620F-IS
More about this item
SPECIFICATIONS | |
CAMERA | |
Image Sensor | 1/3-inches Progressive Scan CMOS |
Min. illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
Shutter time | 1/3 s to 1/100,000s |
Lens | 2.8 ~ 12 mm @F1.4 Angle of view: 113°-33.8° |
Lens mount | Φ14 |
Day & night | IR cut filter with auto switch |
Digital noise reduction | 3D Digital Noise Reduction |
Wide dynamic range | Digital WDR |
Backlight compensation | Yes, zone configurable |
COMPRESSION STANDARD | |
Video compression | H.264 / MJPEG |
H.264 Type | Main Profile |
Bit rate | 32 Kbps – 8 Mbps |
Audio Compression | G.711/G.722.1/G.726/MP2L2 |
Audio Bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
IMAGE | |
Max. Image Resolution | 1920×1080 |
Frame rate | 50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) |
Image settings | Saturation, brightness, contrast, sharpeness adjustable through client software or web browser |
NETWORK | |
Network storage | NAS |
Alarm trigger | Motion detection, Tampering alarm, Network disconnect, IP address confict, Storage full , Storage error |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
General | One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
System compatibility | ONVIF, PSIA, CGI |
General functionalities | User authentication, watermark, dual stream |
INTERFACE | |
Communication interface | 1 RJ45 10M / 100M ethernet port |
Onboard Storage | Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
GENERAL | |
Operating conditions | -30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
Power supply | 12 VDC ± 10% , PoE (802.3af)± 10% |
Power consumption | Max. 5.5W |
Ingress protection level | IP66 |
IR range | 30 meters |
Dimensions (mm) | 95 x 105 x 258.6 mm |
Weight | 1200g |
