| Camera |
| Image Sensor: |
1/3″ Progressive Scan CMOS |
| Min. Illumination: |
0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR |
| Shutter time: |
1/25s ~ 1/100,000s |
| Lens: |
4mm @F2.0, angle of view: 79°
(6mm, 12mm optional) |
| Lens Mount: |
M12 |
| Day& Night: |
IR cut filter with auto switch |
| Wide Dynamic Range: |
Digital WDR |
| Digital noise reduction: |
3D DNR |
|
| Compression Standard |
| Video Compression: |
H.264/M-JPEG |
| Bit Rate: |
32 Kbps ~ 16 Mbps |
| Dual Stream: |
Yes |
|
| Image |
| Max. Image Resolution: |
1920 x 1080 |
| Frame Rate: |
50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720)
60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) |
| Image Settings: |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC: |
Yes, zone configurable |
| ROI: |
Yes, up to 4 configurable areas |
|
| Network |
| Network Storage: |
NAS |
| Alarm Trigger: |
Motion detection, Dynamic Analysis, Tampering alarm |
| Protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour (SIP optional) |
| Security: |
User authentication, watermark |
| System Compatibility: |
ONVIF, PSIA, CGI, ISAPI |
|
| Interface |
| Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
| Reset Button: |
Yes |
|
| General |
| Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: |
Max. 5 W (Max. 7 W with IR cut filter on) |
| Weather Proof: |
IP66 |
| IR Range: |
Up to 30m |
| Dimensions: |
60.4 x 76.9 x 139.2mm |
| Weight: |
500g (1.1 lbs) |
|
