Product code: N/A

DVR HIKVISION 7208HQHI-SH 8 CHANNEL

Rp 4,145,000

Turbo HDVR

H.264 & Dual-stream video compression Support both HD-TVI and analog cameras with adaptive access Support HD-TVI/analog/IP camera triple hybrid Full channel@1080P resolution real-time recording HDMI and VGA output at up to 1920×1080P resolution Long transmission distance over coax cable Support up to 8-ch synchronous playback

More about this item

Spesifikasi

Video/Audio Input
Audio Input:		4-ch
Video Compression:		H.264
Analog and HD-TVI video input:		8-ch,BNC interface (1.0Vp-p, 75 O)
Supported camera types:		720P25, 720P30, 720P50, 720P60, 1080P25, 1080P30, CVBS
IP Video Input:		2-ch 1080P
Video Input Interface:		BNC (1.0 Vp-p, 75O)
Audio Compression:		G.711u
Audio Input Interface:		RCA (2.0 Vp-p, 1 kO)
Two-way Audio:		1-ch, RCA (2.0 Vp-p, 1 KO) (using the 1st channel of audio input)
Video/Audio Output
HDMI/VGA Output:		1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Recording resolution:		Main stream: 1080P / 720P / VGA / WD1 / 4CIF / CIF;Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA
Frame Rate:		Main stream: 1/16 fps ~ Real time frame rate Sub-stream: 1/16 fps ~ Real time frame rate
Video Bit Rate:		32 Kbps-10 Mbps
Audio Output:		1-ch RCA(Linear, 1kO)
Audio Bit Rate:		64kbps
Dual Stream:		Support
Playback Resolution:		1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
Synchronous Playback:		8-ch
Network management
Remote connections:		128
Network protocols:		TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS
Hard Disk Driver
Interface Type:		2 SATA Interfaces
Capacity:		Up to 6 TB capacity for each disk
External Interface
Network Interface:		1; 10M / 100M / 1000M self-adaptive Ethernet interface
USB Interface:		2 USB 2.0 Interfaces
Serial Interface:		1; standard RS-485 serial interface, half-duplex
Alarm Input:		8-ch
Alarm Output:		4-ch
General
Power Supply:		12V DC
Consumption:		= 30W
Working Temperature:		-10 ºC ~ 55 ºC (14 ºF ~ 131 ºF)
Working Humidity:		10% ~ 90%
Chassis:		380mm 1U chassis
Dimensions:		380 × 290 × 48mm (15.0 × 11.4 × 1.9 inch)
Weight:		= 2Kg (4.4lb)
